Medical Titanium Plate 98mm
Usage: Medical
Diameter: Dia.98mm
Tensile Strength/Yield Strength: 907Mpa/837Mpa
Advantage: Good biocompatibility
Feature: Low hardness,non-magnetic
Application: Crowns, implants, etc.
Certificates: ISO 13485 ,FDA ,CE
Description
Technical Parameters
Description
Medical titanium plate 98mm are widely used in dental field, especially in dental restoration. It widely used in the cutting and milling of dental crowns and the processing of dental restoration,abutments & implants. Compared with CoCr materials, it has excellent characteristics such as slight ,non-toxicity and non-magnetism. Do not need to be removed for MRI and other tests. It has a higher cost-effectiveness, better overall performance, longer service life, no rejection, and is safer for the human body.
Technical Parameters
|
General Specs |
|
|
Diameter |
98mm |
|
Thickness |
10mm to 30mm |
|
Tensile Strength |
907MPa(≥825MPa) |
|
Yield Strength |
837MPa(≥760MPa) |
|
Density |
4.51g/cm3 |
|
Hardness |
297 (HV) |
|
Elongation |
16.5%(≥8%) |
|
Reduction of Area |
49%(≥15%) |
|
Enforce Standard |
ASTM F67/ASTM F136 / ISO 5832-2/ISO 5832-3 |
|
Shape |
Round |
|
MOQ |
1pcs |
|
Surface |
Bright |
|
OEM |
Available |
|
Grade |
Grade 2,Grade 5,Grade 5,Eli,Grade 23 |
|
Lead Time |
In stock |
Features
1. Quality control and certification.
Use spectrometer (OES) to detect the composition to ensure that the impurity elements (Fe, O, N, etc.) are strictly limited. Provide third-party test reports (SGS/BV), covering mechanical properties, metallographic structure and non-destructive testing (UT/RT). Special certified materials such as medical grade (ELI) and can be provided according to customer needs
2. Service support
Customized supply: Process special thickness discs according to requirements provide laer priting ,heat treatment (annealing/solid solution) and surface treatment services.
Technical consultation: Assist in material selection optimization, provide machining process guidance.
Medical titanium plate 98mm have become a key material in the high-end dental manufacturing industry due to their irreplaceable performance advantages. We are committed to providing high-quality dental titanium materials that meet international standards, and rely on a complete quality control system to ensure product reliability. If you need further technical parameters or sample testing, please contact our engineering team.
Applications
Due to the surface of Medical titanium plate 98mm machinability, supports precision machining such as turning, grinding, polishing, etc. The surface can be anodized or sandblasted to improve wear resistance and aesthetics ,widely used in the medical field, especially in the field of dental restoration for milling crowns ,implants etc.
